Gastro Video Scopes

Name: Gastro Video Scopes
Brand: GENUINE MEDICA PVT. LTD.
Price: 695000.00 INR
Availability: InStock

Price 695000.00 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Gastro Video Scopes Specification

Phase
Single Phase

Weight
1.5 kg

Automation Grade
Manual

Storage Capacity
Up to 5000 Images

Height
1600 mm (Insertion Tube)

Shape
Tube

Suitable For
Hospitals, Clinics

Use
Diagnostic and Therapeutic Procedures

Temperature Range
10C to 40C

Properties
High Resolution Imaging, Flexible Tube, Waterproof

Dimension (L*W*H)
1600mm x 12mm x 10mm

Product Type
Gastro Video Scope

Treatment Type
Endoscopic Procedures

Material
Stainless Steel, Medical Grade Polymer

Frequency
50 Hz

Color Code
Black and Silver

Display Type
Color

Accuracy
High Precision Imaging

Power
60W

Display
LCD

Power Source
Electric

Voltage
220 V

Gastro Video Scopes Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
10 Pieces Per Month

Delivery Time
2-3 Days

About Gastro Video Scopes

Gastro Video Scopes

We are continuously innovating newer designs that are user friendly as well as efficient. Gastro Video Scopes - Colono Video Scope is our range of product which is really safe and easy in handling also. We offer a proper specifications about our products so that they may be used perfectly. Our Gastro Video Scopes - Colono Video Scopes can be seen at many medical labs of various big medical instituitions.

Super-high Resolution

VMEC series have adopted color charge coupled Device (CCD) with 440k pixels and high sensitivity for good quality images

Handy Operation

VMEC series have used the structure of chain pull for the Bending Section. The operator will not be easy to feel tired as a result of the flexible Control Section.

Completely Water Proof

VMEC series can be immersed completely into detergent solution as disinfection and sterilization. Inspect any defects in time by the Leakage Tester, and protect the endoscope from damaging.

on the fiberoptic light guide. When the lifetime of the lamp (500 hrs.) has expired, the lamp is simply replaced by a new one within seconds - no tool and no adjustment is required.

Connect to Computer

It can enlarge functions. such as collecting and saving frame, memorizing the patient's name. sex, age, doctor's name, description, diagnosing and so on while it connects to computer. and it can print reports with pictures and documents

SPECIFICATION	VMEC N9S	VMEC-P98	VMEC-92	VMEC-92
View of field	140o
Depth of View	3-100mm
Range of tip Bending	U 210o	D90o	L 100o	R 100o
Diameter of Distal-End	6.0mm	7.9mm	9.2mm	9.8mm
Diameter of Insertion Tube	5.9mm	7.8mm	9.0mm	9.6mm
Diameter of Instrumental Channel	2.0mm		2.8mm
Working Length	1050

GASTRO VIDEO SCOPES VMES SERIES

SPECIFICATION	VMES N98	VMES-P98	VMES-92	VMES-98
View of field	140o
Depth of View	3-100mm
Range of tip Bending	U 210o	D90o	L 100o	R 100o
Diameter of Distal-End	6.0mm	7.9mm	9.2mm	9.8mm
Diameter of Insertion Tube	5.9mm	7.8mm	9.0mm	9.6mm
Diameter of Instrumental Channel	2.0mm		2.8mm
Working Length	1050

SPECIFICATION

Specifications	VMEC - 2000
Light Source	Dual - Halogen Lamps Built in
Dimensions	410 (L) X 380 (W) X 115 (H)
Weight	15 kgs
Format Encoding	PAL
Frames Frozen	1/4 Frames Frozen
Power Supply	Voltage 110/220V~240V, Frequency 50Hz ~ 60 Hz
Power Consumption	200W
Security Standard	GB9706.1/IEC601-1

Advanced Imaging Technology

Equipped with high-resolution, color LCD displays, our Gastro Video Scopes offer clear, precise images essential for accurate diagnosis and treatment. The flexible tube and waterproof construction ensure reliable performance across diverse clinical cases, while the enhanced storage capacity allows clinicians to record and review up to 5000 images per procedure.

Robust and Reliable Construction

Built with stainless steel and medical grade polymer, these scopes are designed for longevity and frequent usage in demanding hospital and clinic environments. The waterproof and flexible tube facilitates complex procedures, while the lightweight 1.5 kg design makes handling comfortable for medical professionals throughout lengthy treatments.

FAQs of Gastro Video Scopes:

Q: How do I operate the Gastro Video Scope during endoscopic procedures?

A: Simply connect the device to a 220 V power source, switch on the electric system (60W), and use the flexible, 1600mm insertion tube to guide the scope. Images are displayed on the color LCD in real-time, enabling precise navigation and intervention.

Q: What are the main benefits of using this scope in medical settings?

A: The scope delivers high-resolution, color images with high precision, aiding accurate diagnoses and effective therapeutic procedures. Its waterproof and flexible design enhances safety and accessibility for both patient and clinician.

Q: Where can the Gastro Video Scopes be used effectively?

A: These scopes are ideal for use in hospital and clinic environments throughout India, accommodating both diagnostic and therapeutic gastrointestinal procedures thanks to their robust build and advanced imaging features.

Q: What is the storage process for procedure images on this device?

A: The scope can store up to 5000 images internally per session, allowing clinicians to document and review procedural visuals for future reference, teaching, and patient records.

Q: Which cleaning and maintenance steps are recommended after procedures?

A: After each use, thoroughly clean and disinfect the waterproof, stainless steel, and polymer surfaces according to hospital protocols to maintain hygiene and prolong the scopes lifespan.

Q: When should the scope be used within its operating temperature range?

A: For optimal performance and safety, use and store the device within temperatures of 10C to 40C, as recommended for medical equipment of this sensitivity.
