Cysto scope

Name: Cysto scope
Brand: GENUINE MEDICA PVT. LTD.
Price: 130000.00 INR
Availability: InStock

Price 130000.00 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Cysto scope Specification

Display Type
Optical/Through eyepiece (optional video)

Weight
Approx. 0.5 kg

Power
No direct electrical power required (manual optical instrument)

Product Type
Cysto Scope

Automation Grade
Manual

Temperature Range
15C to 40C (operational)

Color Code
Silver & Black

Suitable For
Hospitals, Clinics, Urology Departments

Use
Direct visualization of urinary bladder and urethra

Shape
Rigid, Straight

Application
Urological Endoscopy / Cystoscopy Procedures

Function
Visualization and diagnosis during cystoscopy

Properties
Autoclavable, Corrosion Resistant, Precision Crafted

Material
Stainless Steel & Medical Grade Polymer

Dimension (L*W*H)
330 mm x 4 mm (shaft diameter)

Height
330 mm (length of instrument)

Accuracy
High optical resolution for medical use

Humidity Range
10% - 90% (non-condensing)

Treatment Type
Diagnostic, Therapeutic (if required with accessories)

Phase
Single Phase

Display
Requires external camera system or direct eyepiece

Power Source
Not applicable (manual optical device)

Surface Finish
Mirror polished for easy cleaning

Eyepiece Type
Wide angle, focusing eyepiece

Working Length
330 mm

Resolution
Medical high-definition optical clarity

Angle of View
30° (other options available: 0°, 70°)

Shaft Diameter
4 mm

Sterilization
Autoclavable at 134°C

Light Transmission
High-intensity for enhanced illumination

End Tip Type
Oblique or straight, atraumatic

Compatibility
Compatible with standard cystoscope sheaths and accessories

Field of View
100°

Irrigation Channel
Provided for saline/fluid irrigation

Optical System
Rod lens system for clear image

Connector
Standard light cable adapter

Cysto scope Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
10 Pieces Per Month

Delivery Time
2-3 Days

About Cysto scope

Cystoscope

Cystoscope provided by us, is widely manufactured and supplied by our company by making use of high-quality raw materials and upgraded technology under the guidance of our workers. This device is mainly used to diagnose, monitor and treat conditions affecting the bladder and urethra. This equipment is very effective and provides accurate information too. Cystoscope helps your doctor to view your lower urinary tract for abnormalities in the urethra and bladder. This procedure helps the doctor to clearly examine the root cause of the problem for better treatment. This device is very cost effective and can be easily purchased by our eminent clients at cheaper rates, in bulk quantities.

Made up of high quality alloy steel
Storage comaptible
One year warranty

High Definition Visualization for Precision Diagnosis

Utilizing a rod lens optical system, the cystoscope provides exceptional image clarity essential for accurate diagnosis and treatment. The high-intensity light transmission and wide-angle field of view (100) enhance the visualization of the bladder and urethra, helping clinicians identify abnormalities with confidence during cystoscopy procedures.

Flexible Angles and User Comfort

The cystoscope offers multiple angles of view 0, 30, and 70 suitable for varying anatomical needs and clinical scenarios. Its focusing eyepiece and oblique or straight atraumatic tips improve maneuverability and patient comfort during diagnostic or therapeutic interventions, ensuring both precision and safety.

Simple Sterilization and Seamless Integration

Crafted for medical environments, this cystoscope is autoclavable at 134C and features a mirror-polished finish to simplify cleaning. It integrates effortlessly with standard cystoscope sheaths, accessories, and light cable adapters, streamlining setup and supporting high-volume practices in hospitals and clinics.

FAQs of Cysto scope:

Q: How is the cystoscope sterilized for repeated medical use?

A: The cystoscope is autoclavable at 134C, allowing thorough sterilization between procedures. Its mirror-polished surface makes cleaning easy and ensures minimal risk of contamination.

Q: What advantages does the rod lens optical system provide compared to other cystoscopes?

A: The rod lens system delivers high-resolution, medical-grade optical clarity, allowing clinicians to visualize fine details during urological examinations for accurate diagnosis.

Q: When should different angles of view (0, 30, 70) be used?

A: Different angles accommodate specific clinical scenarios; for example, 0 provides direct visualization, 30 offers a broader perspective, while 70 facilitates examination of hard-to-reach areas within the bladder.

Q: Where can this cystoscope be used effectively?

A: The cystoscope is suitable for use in hospitals, clinics, and urology departments, supporting both diagnostic and therapeutic cystoscopy procedures.

Q: What is the process for visualizing the urinary bladder using this cystoscope?

A: A clinician inserts the cystoscope through the urethra, using the irrigation channel for saline flow to maintain clear visibility. Visualization is achieved via the wide-angle eyepiece or by connecting to an external camera system if required.

Q: How does the wide-angle eyepiece enhance the examination?

A: The wide-angle, focusing eyepiece allows clinicians to view a larger area at once with adjustable focus, improving accuracy and reducing examination time for patient comfort.

Q: What benefits does mirror-polished finishing provide?

A: The mirror-polished surface resists corrosion, simplifies cleaning after procedures, and maintains the cystoscopes high optical performance even after repeated sterilization.
