    Gastro Video Scopes

    Gastro Video Scopes
    Gastro Video Scopes
    Product Code : VMEC
    Brand Name : GENUINE
    Product Description

    Gastro Video Scopes

    We are continuously innovating newer designs that are user friendly as well as efficient. Gastro Video Scopes - Colono Video Scope is our range of product which is really safe and easy in handling also. We offer a proper specifications about our products so that they may be used perfectly. Our Gastro Video Scopes - Colono Video Scopes can be seen at many medical labs of various big medical instituitions.

    Super-high Resolution


    VMEC series have adopted color charge coupled Device (CCD) with 440k pixels and high sensitivity for good quality images

    Handy Operation

    VMEC series have used the structure of chain pull for the Bending Section. The operator will not be easy to feel tired as a result of the flexible Control Section.


    Completely Water Proof

    VMEC series can be immersed completely into detergent solution as disinfection and sterilization. Inspect any defects in time by the Leakage Tester, and protect the endoscope from damaging.

    on the fiberoptic light guide. When the lifetime of the lamp (500 hrs.) has expired, the lamp is simply replaced by a new one within seconds - no tool and no adjustment is required.

    Connect to Computer

    It can enlarge functions. such as collecting and saving frame, memorizing the patient's name. sex, age, doctor's name, description, diagnosing and so on while it connects to computer. and it can print reports with pictures and documents

    SPECIFICATION

    VMEC N9S

    VMEC-P98

    VMEC-92

    VMEC-92

    View of field

    140o

    Depth of View

    3-100mm

    Range of tip Bending

    U 210o

    D90o

    L 100o

    R 100o

    Diameter of Distal-End

     6.0mm

     7.9mm

     9.2mm

     9.8mm

    Diameter of Insertion Tube

     5.9mm

     7.8mm

    9.0mm

     9.6mm

    Diameter of Instrumental Channel

    2.0mm

     2.8mm

    Working Length

    1050



    GASTRO VIDEO SCOPES VMES SERIES

    SPECIFICATION

    VMES N98

    VMES-P98

    VMES-92

    VMES-98

    View of field

    140o

    Depth of View

    3-100mm

    Range of tip Bending

    U 210o

    D90o

    L 100o

    R 100o

    Diameter of Distal-End

     6.0mm

     7.9mm

     9.2mm

    9.8mm

    Diameter of Insertion Tube

    5.9mm

     7.8mm

     9.0mm

     9.6mm

    Diameter of Instrumental Channel

    2.0mm

    2.8mm

    Working Length

    1050



    SPECIFICATION

    Specifications

    VMEC - 2000

    Light Source

    Dual - Halogen Lamps Built in

    Dimensions

    410 (L) X 380 (W) X 115 (H)

    Weight

    15 kgs

    Format Encoding

    PAL

    Frames Frozen

    1/4 Frames Frozen

    Power Supply

    Voltage 110/220V~240V, Frequency 50Hz ~ 60 Hz

    Power Consumption

    200W

    Security Standard

    GB9706.1/IEC601-1
